液壓油缸的材質及油缸選用計算

本文給大家說說液壓油缸的組成材質及油缸的選用計算。

一、液壓油缸的組成材質

1、缸筒：常用材質爲20、35、45號無縫鋼管，鋼管經過珩磨或者滾壓，達到0.4μm以內的粗糙度要求。低壓油缸可采用20號鋼管，高壓油缸采用45號鋼管。

2、活塞桿：活塞桿有實心桿和空心桿兩種，空心活塞桿的一端需要留出焊接和熱處理時用的通氣孔實心活塞桿材料爲35、45鋼，空心活塞桿材料爲35、45無縫鋼管?；钊麠U粗加工后調質到硬度爲229-285HB，必要時，再經高頻淬火，硬度達45-55HRC。

3、活塞：常用材料爲耐磨鑄鐵、灰鑄鐵（HT300、HT350）、鋼及鋁合金?；钊突钊麠U的同軸度公差值應爲0.03mm。

4、缸蓋：低壓用鑄件，中低壓用HT300灰鐵，中高壓用35、45號鋼。當缸蓋本身又是活塞桿的導向套時，缸蓋選用鑄鐵。同時，應在導向表面上熔堆黃銅、青銅或其它耐磨材料。如果采用在缸蓋中壓入導向套的結構時，導向套則應爲耐磨鑄鐵、青銅或黃銅。

二、液壓油缸型號選擇計算

液壓缸型號選擇，主要爲液壓缸的內徑和使用壓力。

例：行程爲300MM，推力爲4000KG，該選用那種型號的液壓缸？

按推力4T，根據公式F=PS（F爲推力、P爲壓力、S爲內徑面積）可以推算，如果油缸的使用壓力設計爲8MPa，則油缸內徑爲80，油缸型號爲80/40*300-8MPa，可采用拉桿油缸，維修方便。

如果油缸的使用壓力選用16MPa，則同理根據上述公式計算油缸內徑選63即可，油缸型號爲63/35*300-16MPa，可采用焊接式或拉桿式。

建議結合機械設備的系統壓力，先確定油缸使用壓力。機械設備爲精加工，則液壓系統壓力選擇低一些，通常在5MPa以下，如果粗加工，則系統壓力選大一些。確定了設備的系統壓力，再去推算油缸內徑，在決定油缸的連接方式，安裝方式，活塞桿端螺紋，安裝具體尺寸等。當油缸的安裝方式與推算過程也關系，比如油缸是豎著裝，水平裝，還是有角度的。

安頌

臺灣ANSON安頌VP5F-A3-50 PVF-30-35-10S VP5FD-A3-A2-50
臺灣安頌ANSON液壓油泵既有效率，高壓下穩定旋轉，反應靈敏，精度高，流量穩定，可以減少馬力的流失等等特點。葉片泵多式多樣，有單聯泵，雙聯泵，單聯和雙聯的又分開加長和標準的。油泵用到整機上后，噪音不大，可以達到比較理想的寧靜的工作環境。
1、變量葉片泵PVF高效率，高壓下穩定旋轉。特殊壓力控制機構，凸輪環3點支撐方式，使在大幅提高時的旋轉性能，在140bar下亦可發揮高效率，穩定的性能。
2、變量葉片泵PVF高效率，高壓下穩定旋轉。采用數種隔音，防振的新機構，尤其可提高凸輪環旋轉的穩定性。由控制活塞，偏位活塞所形成的特殊3點支撐方式，減少凸輪環振動，旋轉時務噪音。
3、變量葉片泵PVF反應靈敏，精度夠。嶄新的凸輪環控制機構，凸輪環無過位移，而提高反應靈敏度。啟動，停止，負荷變動時不會改變精密度。
4、變量葉片泵PVF靈敏的特性，流量穩定。嶄新的壓力平衡式壓力控制機構，在高壓狀態下流量亦高度的穩定順暢。
5、變量葉片泵PVF高效率旋轉，減少馬力損失。采用新機構減少損失馬力，尤其是高壓無輸出狀態時，更明顯的減少馬力損失。
6、變量葉片泵PVF維護，檢修容易。壓力調整裝置和流量調整裝置放在同一側面，方便維護，調整。
